In the first part of this work, ignition of methane-air mixtures under excess air dilution is studied. When excess air is used in SI engine operation, thermal efficiency is increased due to increase in compression ratio together with reduced pumping and heat loses. However, stable operation with excess air is challenging due to poor flammability of the resulting diluted mixture. Hence in order to achieve stable and complete combustion a turbulent jet ignition (TJI) system is used to improve combustion of lean methane-air mixtures. Various nozzle designs and operating strategies for a TJI system were tested in a rapid compression machine. 10-90% burn duration measurements were useful in assessing the performance of the nozzle designs while the 0-10% burn durations indicated if optimal air-fuel ratio is achieved within the pre-chamber at the time of ignition. The results indicated that distributed-jets TJI system offered faster and stable combustion while the concentrated-jets TJI system offered better dilution tolerance.Knock in a SI engine occurs due to autoignition of the end gas mixture and typically occurs in the negative temperature coefficient (NTC) region of the fuel-air mixture. Dilution of intake charge with cold exhaust recirculation gases (EGR) reduces combustion temperatures and decreases mixture reactivity thereby reducing knocking tendency. This enables optimal spark timings to be used, thereby increasing efficiency of SI engines which would otherwise be knock limited. Effect of cold EGR dilution is studied in the RCM by measuring the autoignition delay times of gasoline and gasoline surrogate mixtures diluted with varying levels of CO2. The autoignition experiments in the RCM were performed using a novel direct test chamber (DTC) charge preparation approach. The DTC approach enabled mixture preparation directly within the combustion chamber and eliminated the need for mixing tanks. Effect of CO2 dilution in retarding the autoignition delay times was more pronounced in the NTC region, while it was weaker in the low temperature and high temperature regions. The retarding effect was found to be dependent on both the octane number and the fuel composition of the gasoline being studied.Finally, the effect of substituting ethanol(biofuel) in gasoline surrogates for up to 40% by volume is studied. Ethanol is an octane booster, but it blends antagonistically with aromatics such as toluene and synergistically with alkanes with respect to the resulting octane number of the blends. In order to study this blending effect, two gasoline surrogates containing only alkanes (PRF), and alkanes with large amounts of toluene (TRF) are blended with varying levels of ethanol. The ignition delay times of the resulting mixtures are measured in a rapid compression machine and kinetic analysis was carried out using numerical simulations. The kinetic analysis revealed that ethanol controlled the final stages of ignition for the PRF blends when more than 10% by volume of ethanol is present. However, in the TRF blends, toluene controlled the ignition until mole fractions of ethanol became higher than the toluene indicating the reason for the antagonistic blending nature. It was found that the RON values of the resulting blends matched the trend of the ignition delay times recorded at 740K and 21 bar compressed conditions. This enables qualitative assessment of the RON numbers for new biofuel blends by measuring their ignition delay times in the RCM.
